Processing Raw Data for PTMsToPathways

Purpose

This vignette intends to help users produce a matrix with PTM names as row names (e.g. FYN p Y411) and numeric data in the columns. The numeric values are the mass spectrometer output, and NAs represent missing data rather than zeroes. Ambiguous PTMs, where a PTM could match several proteins, must be separated by semicolons (for example, "AARS ubi k747; AMBLIL p U123").

Mass spectrometry data output will vary depending on the experimental design, source of data, and software used to process the raw spectra. R supports many file types and can automatically convert them into a data frame. For example, read.csv() will take a csv file and convert it into a data frame (read.csv() is a variation of read.table()). We start with data in tab-delimited spreadsheet format.

Naming conventions

In this vignette, we use the following shorthand conventions when describing PTMs based on the modifications present in the example data set. Your data will dictate the names of modifications.

Gene.Name = The HUGO Gene Name is used to identify the protein/gene
Phosphorylation = “p”
Lysine acetylation = “ack”
Lysine methylation = “kme”
Arginine methylation = “rme”
Ubiquitination = “ubi”

Preprocessing data

First, let’s load the P2P package, since it contains some helpful pre-processing functions.

library(PTMsToPathways)

The example raw data file for this vignette (downloadable here, or load directly into R using the commands below) contains only phosphorylation sites.

To prepare data for input to PTMsTo pathways, we first read in the data file. To use your own data file, replace file_path variable with your own path to file, as in the commented line below.

# file_path <- "path/to/your/file.txt"
file_path <- system.file("extdata", "phospho_cleaned_mapped.txt",
                         package = "PTMsToPathways")

newphos <- utils::read.table(file_path, sep = "\t", skip = 0, header = TRUE,
                             blank.lines.skip = T, fill = T, quote = "\"", dec = ".",
                             comment.char = "", stringsAsFactors = F)
dim(newphos)
>> [1] 933 170

As we can see, this table has 933 rows and 170 columns.

First remove internal control rows (reverse sequences), which should yield 908 remaining rows.

newphos <- newphos[!is.na(newphos$AllGeneSymbols),]
dim(newphos)
>> [1] 908 170

Many investigators inspect data in Microsoft Excel, which can export tab- or comma-delimited files. Unfortunately, Excel can silently convert some gene names into dates when they appear in a cell by themselves. We reverse that with the P2P helper function fix.excel(). If there are dates in the AllGeneSymbols column, we can apply the fix.excel() function to each of them to convert them back to gene names.

newphos$AllGeneSymbols <- sapply(newphos$AllGeneSymbols, fix.excel)

Investigators will need to identify which columns contain key information for analysis of PTMs.

In this example, the key columns are:

Amino.Acid: the modified amino acid, such as S or T
Positions.Within.Proteins: the amino acid number in the protein sequence
Modification.Type: the PTM class, such as phosphorylation
AllGeneSymbols: the HUGO gene name(s) of the protein(s) containing the PTM, separated by “;” if more than one

newphos.header <- newphos[,c("AllGeneSymbols", "Amino.Acid",
                "Positions.Within.Proteins", "Modification.Type")]

head(newphos.header)
>>    AllGeneSymbols Amino.Acid Positions.Within.Proteins     Modification.Type
>> 1      KRT7;NA;NA          S                  37;37;37 Phosphorylation (STY)
>> 2      KRT7;NA;NA          S                  38;38;38 Phosphorylation (STY)
>> 10         INPPL1          S                       890 Phosphorylation (STY)
>> 11          KDM6A          S                       388 Phosphorylation (STY)
>> 12         DIAPH1          S                       373 Phosphorylation (STY)
>> 13         CTNND1          S                       252 Phosphorylation (STY)

We provide another helper function, name.peptide(), to handle ambiguous modification sites (a modification site whose peptide sequence is the same in more than one protein) separated by “;” or another separator.

newphos.header$Peptide.Name <- mapply(
  name.peptide, genes = newphos$AllGeneSymbols,
  sites =  newphos$Positions.Within.Proteins, aa = newphos$Amino.Acid)
head(newphos.header)
>>    AllGeneSymbols Amino.Acid Positions.Within.Proteins     Modification.Type
>> 1      KRT7;NA;NA          S                  37;37;37 Phosphorylation (STY)
>> 2      KRT7;NA;NA          S                  38;38;38 Phosphorylation (STY)
>> 10         INPPL1          S                       890 Phosphorylation (STY)
>> 11          KDM6A          S                       388 Phosphorylation (STY)
>> 12         DIAPH1          S                       373 Phosphorylation (STY)
>> 13         CTNND1          S                       252 Phosphorylation (STY)
>>     Peptide.Name
>> 1     KRT7 p S37
>> 2     KRT7 p S38
>> 10 INPPL1 p S890
>> 11  KDM6A p S388
>> 12 DIAPH1 p S373
>> 13 CTNND1 p S252

Data columns

Next we identify the data columns, which contain the string Intensity. The example data file is from a multi-PTM study and the data in this table are from just the phosphorylation pulldown (other tables are for other PTM types). The optimal pulldown columns are straightforward to identify by the pulldown strings present in the sample names, pTyr in this case. They are also identifiable by zooming out and looking at the patterns of missing data, the optimal pulldowns, as a group, have the least missing data. In this data, the following abbreviations are used: C = Crizotinib, D = DMSO, E = Erlotinib, Pr = PR171. So for example the first four columns can be interpreted as:

names(newphos)[grep("Intensity", names(newphos))][1]
>> [1] "Intensity.H3122SEPTM_AcK.C1.1"

C1.1: Crizotinib biological replicate 1- technical replicate 1

names(newphos)[grep("Intensity", names(newphos))][2]
>> [1] "Intensity.H3122SEPTM_AcK.C1.2"

C1.2: Crizotinib biological replicate 1- technical replicate 2

names(newphos)[grep("Intensity", names(newphos))][3]
>> [1] "Intensity.H3122SEPTM_AcK.C2.1"

C2.1: Crizotinib biological replicate 2- technical replicate 1

names(newphos)[grep("Intensity", names(newphos))][4]
>> [1] "Intensity.H3122SEPTM_AcK.C2.2"

C2.2: Crizotinib biological replicate 2- technical replicate 2

So, we first select columns that contain the string Intensity. There should be 108 of these:

data.cols <- newphos[,grep("Intensity", names(newphos))]
dim(data.cols)
>> [1] 908 108

And then select colums that have pTyr. There should be 36 of these:

data.cols <- newphos[,grep("pTyr", names(newphos))]
dim(data.cols)
>> [1] 908  36

Now simplify column names (remove Intensity):

names(data.cols) <- sapply(names(data.cols), function(x){
  unlist(strsplit(x, "Intensity."))[2]
  })
head(names(data.cols))
>> [1] "H3122SEPTM_pTyr.C1.1" "H3122SEPTM_pTyr.C1.2" "H3122SEPTM_pTyr.C2.1"
>> [4] "H3122SEPTM_pTyr.C2.2" "H3122SEPTM_pTyr.C3.1" "H3122SEPTM_pTyr.C3.2"

Make zero into NA, which it is. (Note that this may not apply if you are confident that zero means actual zero, which is possible with certain technical advances like DIA.) We should have 16265 NA values.

zer0 <- which(data.cols==0, arr.ind = TRUE)
data.cols <- replace (data.cols, zer0, NA)
sum(is.na(data.cols))
>> [1] 16265

Merge techincal replicates

These data have technical replicates, which means that the same samples were run twice. Due to the stochastic selection of peptides for detection, the pattern of missing values is slightly different between technical replicates. We therefore merge the technical replicates taking the value of either replicate where it’s missing in the other, and averaging values detected in both, using the P2P function merge2cols().

Define technical replicates:

tr1.opt <- names(data.cols)[grep(".1", names(data.cols), fixed=TRUE)]
tr2.opt <- names(data.cols)[grep(".2", names(data.cols), fixed=TRUE)]
tr1.opt[1]
tr2.opt[1]
>> [1] "H3122SEPTM_pTyr.C1.1"
>> [1] "H3122SEPTM_pTyr.C1.2"

Use merge2cols() to average technical replicates. This function ignores NA values in either column and takes the average in the case where there are two values. In this case, the resulting data frame should have 18 total columns, one for each biological replicate.

phosdata.merged <- data.frame(matrix(nrow = nrow(data.cols), ncol = length(tr1.opt)))
for (i in seq_along(tr1.opt)) {
phosdata.merged[, i] <- merge2cols(
data.cols[, tr1.opt[i]],
data.cols[, tr2.opt[i]]
)}
dim(phosdata.merged)

>> [1] 908  18

And fix up the names of the merged columns to remove the technical replicate numbers:

names(phosdata.merged) <- sapply(tr1.opt, function(x){
  substr(x, start=1, stop=nchar(x)-2)
  })
names(phosdata.merged)[1]
>> [1] "H3122SEPTM_pTyr.C1"

Merge the header and the data together to make a complete data set:

phosdatafile <- cbind(newphos.header, phosdata.merged)
dim(phosdatafile)
>> [1] 908  23

This file could be saved for reference using write.table():

write.table(phosdatafile, file = "phosdatafile.txt",
            row.names = FALSE, sep = "\t")

For input into P2P, we want the row names to be the PTM names and the columns just to be the merged technical replicate columns, so we just use that data and set the row names to the Peptide.Name column:

phosdata.df <- phosdata.merged
rownames(phosdata.df) <- phosdatafile$Peptide.Name

Notice that this data is the same as the ex_small_ptm_table that is provided with the package (though the column names are slightly different):

all.equal(setNames(phosdata.df, NULL), setNames(ex_small_ptm_table, NULL))
>> [1] TRUE

Log base 2 transformation improves clustering.

log2phosdata <- log2(phosdata.merged)

The Creating Networks vignette show how to use the functions provided in PTMsToPathways to analyze data stored in a variable called ptmtable.

ptmtable <- log2phosdata

Optional data processing steps

For experiments where treatment with drugs is compared to control samples, adding treatment/control ratios as additional data column can improve clustering. This optional step adds dimensions to the data set that enhance focus on the changes in response to drug treatments.

Simplify column names first:

names(phosdata.df) <- sapply(names(phosdata.df), function(x){
  paste(unlist(strsplit(x, "SEPTM_pTyr"))[1],
        unlist(strsplit(x, "SEPTM_pTyr"))[2], sep = "")
  })

Explore using ratios where control=rowMeans (D1, D2, D3):

H3122control <- rowMeans(phosdata.df[, names(phosdata.df)
                                     [grep("H3122.D", names(phosdata.df))]],
                         na.rm=TRUE)

Change NaN to NA

H3122control[is.nan(H3122control)] <- NA

PC9control <- rowMeans(phosdata.df[, names(phosdata.df)
                                   [grep("PC9.D", names(phosdata.df))]],
                       na.rm=TRUE)

PC9control[is.nan(PC9control)] <- NA

Calculate treatment/control ratios

# H3122 cells
H3122.C1.ratio <- phosdata.df$H3122.C1/H3122control
H3122.C2.ratio <- phosdata.df$H3122.C2/H3122control
H3122.C3.ratio <- phosdata.df$H3122.C3/H3122control
H3122.PR1.ratio <- phosdata.df$H3122.PR1/H3122control
H3122.PR2.ratio <- phosdata.df$H3122.PR2/H3122control
H3122.PR3.ratio <- phosdata.df$H3122.PR3/H3122control

# PC9 cells
PC9.E1.ratio <- phosdata.df$PC9.E1/PC9control
PC9.E2.ratio <- phosdata.df$PC9.E2/PC9control
PC9.E3.ratio <- phosdata.df$PC9.E3/PC9control
PC9.PR1.ratio <- phosdata.df$PC9.PR1/PC9control
PC9.PR2.ratio <- phosdata.df$PC9.PR2/PC9control
PC9.PR3.ratio <- phosdata.df$PC9.PR3/PC9control

Put these columns in a data frame:

phos_ratios <- data.frame(H3122.C1.ratio, H3122.C2.ratio, H3122.C3.ratio,
                          H3122.PR1.ratio, H3122.PR2.ratio, H3122.PR3.ratio,
                          PC9.E1.ratio, PC9.E2.ratio, PC9.E3.ratio,
                          PC9.PR1.ratio, PC9.PR2.ratio, PC9.PR3.ratio)

Check (should be TRUE):

identical(rownames(phosdata.df), rownames(phos_ratios))
>> [1] TRUE

Make limits to unweight extreme values. This has been shown to improve clustering, and a ratio of 1000 is biologically not really functional different than a ratio of 100.

hi.ratio <- which(phos_ratios >= 100, arr.ind = TRUE)
low.ratio <- which(phos_ratios <= 1/100, arr.ind = TRUE)
phos_ratios.lim <- replace (phos_ratios, hi.ratio, 100)
phos_ratios.lim <- replace (phos_ratios.lim, low.ratio, 1/100)

log2 transformation improves clustering:

phos_ratios.lim.log2 <- log2(phos_ratios.lim)
phosdata_plus_ratios <- cbind(log2phosdata, phos_ratios.lim.log2)

And plot to check:

boxplot(phosdata_plus_ratios)

And do one more check:

identical(rownames(phos_ratios.lim.log2), rownames(log2phosdata))
>> [1] FALSE

This can be used as the example ptmtable for subsequent testing.

# ptmtable <- phosdata_plus_ratios

Combining data from multiple PTM experiments

For experiments involving multiple PTMs, or if investigators wish to combine several data sets, the data can be combined. For example, pulldowns were made to isolate acetylated and ubiquitinated peptides from the same experimental samples. Combining the data is simply repeating the above steps using the correct optimum data columns, then making the column names the same, and binding all the rows together.

Suppose you had acetylation data in ackdata.df and ubiquitination data in ubidata.df, both formatted as above for phosphorylation data in phosdata.df. You could combine them as follows.

First, make sure the column names are the same:

kgp <- phosdata.df
kga <- ackdata.df
kgu <- ubidata.df

names(kgp) <- sapply(names(kgp), function(x){
  paste(unlist(strsplit(x, "_pTyr"))[1], unlist(strsplit(x, "_pTyr"))[2],
        sep = "")
  })

names(kga) <- sapply(names(kga), function(x){
  paste(unlist(strsplit(x, "_AcK"))[1], unlist(strsplit(x, "_AcK"))[2],
        sep = "")
  })

names(kgu) <- sapply(names(kgu), function(x){
  paste(unlist(strsplit(x, "_Ubi"))[1], unlist(strsplit(x, "_Ubi"))[2],
        sep = "")
  })

identical(names(kgp), names(kga)) # Check TRUE

Then rbind them:

ptmdata <- rbind (kgp, kga, kgu)

Reorder:

ptmdata <- ptmdata[order(rownames(ptmdata)),]

This optional step improves clustering in our hands:

log2ptmdata <- log2(ptmdata)

Finally, this dataframe could be used as the example ptmtable for the P2P functions.

# ptmtable <- log2ptmdata

Session info

sessionInfo()
>> R version 4.6.1 (2026-06-24)
>> Platform: x86_64-pc-linux-gnu
>> Running under: Ubuntu 24.04.4 LTS
>>
>> Matrix products: default
>> BLAS:   /usr/lib/x86_64-linux-gnu/openblas-pthread/libblas.so.3
>> LAPACK: /usr/lib/x86_64-linux-gnu/openblas-pthread/libopenblasp-r0.3.26.so;  LAPACK version 3.12.0
>>
>> locale:
>>  [1] LC_CTYPE=C.UTF-8       LC_NUMERIC=C           LC_TIME=C.UTF-8
>>  [4] LC_COLLATE=C.UTF-8     LC_MONETARY=C.UTF-8    LC_MESSAGES=C.UTF-8
>>  [7] LC_PAPER=C.UTF-8       LC_NAME=C              LC_ADDRESS=C
>> [10] LC_TELEPHONE=C         LC_MEASUREMENT=C.UTF-8 LC_IDENTIFICATION=C
>>
>> time zone: UTC
>> tzcode source: system (glibc)
>>
>> attached base packages:
>> [1] stats     graphics  grDevices utils     datasets  methods   base
>>
>> other attached packages:
>> [1] PTMsToPathways_0.99.0
>>
>> loaded via a namespace (and not attached):
>>  [1] digest_0.6.39     desc_1.4.3        R6_2.6.1          fastmap_1.2.0
>>  [5] xfun_0.59         cachem_1.1.0      knitr_1.51        htmltools_0.5.9
>>  [9] rmarkdown_2.31    lifecycle_1.0.5   cli_3.6.6         sass_0.4.10
>> [13] pkgdown_2.2.0     textshaping_1.0.5 jquerylib_0.1.4   systemfonts_1.3.2
>> [17] compiler_4.6.1    tools_4.6.1       ragg_1.5.2        bslib_0.11.0
>> [21] evaluate_1.0.5    yaml_2.3.12       otel_0.2.0        jsonlite_2.0.0
>> [25] rlang_1.2.0       fs_2.1.0

Lucia Williams, Nagashree Avabhrath, Mikhail Ukrainetz, Madison Moffett, Grant Smith, Mark Grimes
