Visualization Options

Cytoscape allows us to encode information in the visual network attributes node size, color, shape, and border and edge color, size, and arrow type. In this vignette, we use node attributes to represent the type of protein this gene is and edge attributes to represent different types of interactions from PPI databases, correlations, or links between proteins and their PTMs. Further details can be found by clicking to expand the following table.

Show Detailed Network Attribute Table
Attribute Options
Node Size Greater the node size, larger the absolute value of the amount or ratio
Node Color Blue: Negative ratio
Yellow: Positive ratio
Green: Approximately zero ratio
Node Shape ELLIPSE: unknown
ROUND_RECTANGLE: Receptor Tyrosine Kinase
VEE: SH2 Protein or SH2-SH3 Protein
TRIANGLE: SH3 Protein
HEXAGON: Tyrosine Kinase
DIAMOND: SRC-family Kinase
OCTAGON: Kinase or Phosphatase
PARALLELOGRAM: Transcription Factor
RECTANGLE: RNA Binding Protein
Node Border Colors Orange: Deacetylase or Acetyltransferase
Blue: Demethylase or Methyltransferase
Royal Purple: Membrane Protein
Red: Kinase, Tyrosine Kinase, or SRC-family Kinase
Yellow: Phosphatase or Tyrosine Phosphatase
Lilac: G Protein-Coupled Receptor
Grey: Default
Edge Colors Red: Phosphorylation, pp, or Controls-Phosphorylation-of
Bright Magenta: Controls-Expression-of
Dull Magenta: Controls-Transport-of
Purple: Controls-state-change-of
Blood Orange: Acetylation
Lime Green: Physical Interactions
Green: BioPlex
Dull Green: In-Complex-With
Seafoam Green: Experiments or Experiments_Transferred
Cyan: Database or Database_Transferred
Teal: Pathway or Predicted
Dark Turquoise: Genetic Interactions
Yellow-Orange: Correlation
Royal Blue: Negative Correlation
Bright Yellow: Positive Correlation
Grey: Combined_Amount or Ratio
Dark Grey: Merged
Light Grey: Intersect
Black: Peptide
Orange: Homology
Dull Orange: Shared Protein Domains
White: Default
Arrow Types Arrow: Phosphorylation, pp, Controls-Phosphorylation-of, Controls-Expression-of, Controls-Transport-of, Controls-State-Change-of, Acetylation
No Arrow: Default


To visualize the information in this table, NodeEdgeKey function generates an example network in Cytoscape like the one shown below.

Node information is based on a function key that maps gene names to a table of information regarding the gene. This may be provided by the user or PTMsToPathways provides an example dataset as function_key.

head(function_key[1:3])
Gene.Name Approved.Name Hugo.Gene.Family
A1BG alpha-1-B glycoprotein Immunoglobulin-like domain containing
A1CF APOBEC1 complementation factor RNA binding motif containing
A2LD1 undefined undefined
A2M alpha-2-macroglobulin undefined
A2ML1 alpha-2-macroglobulin-like 1 undefined
A3GALT2 alpha 1,3-galactosyltransferase 2 Glycosyltransferase family 6

Top-Down Approach

It is possible to graph the entire PCN, CFN, and CCCNs in their entirety, though very large graphs take a long time to graph. One approach to navigating these data structures is to select nodes from the large networks in Cytoscape (or in R using RCy3::selectNodes) and select nearest neighbors or shortest paths and create a subnetwork in a new window (see the Cytoscape Manual).

The alternative approach described below is to identify pathways, genes, and PTMs of interest in the R data objects, then make smaller, more interpretable graphs in Cytoscape using RCy3.

We’ll explore this approach using two different examples: investigating a pair of pathways and exploring signaling pathways that connect proteins.

Investigate a Pair of Pathways

First, we read in Bioplanet pathways into pathways.list using the P2P function ReadBioplanetFile. Here, the name of each liist element is the name of a Bioplanet pathway that maps to a list of genes in that pathway.

bioplanet.path <- system.file("extdata",
                              "bioplanet_pathway_June2025.csv",
                              package = "PTMsToPathways")
pathways.list <- ReadBioplanetFile(bioplanet.file = bioplanet.path)

Next, we filter to the pathways that contain epidermal growth factor receptors (EGFRs).

egfr_pathways <- names(pathways.list)[sapply(1:length(pathways.list), function(x)
  {"EGFR" %in% pathways.list[[x]]})]

We expect 83 pathways that contain EGFR, so let’s check:

length(egfr_pathways)
>> [1] 83

Then, we want to find interactions between the pathway “Transmembrane transport of small molecules” and those pathways. For now, we are manually adding an entry to ex_pathway_crosstalk_network so that the resulting filtered PCN has a row to work with.

pcn.path <- system.file("extdata",
                        "full_pathway_crosstalk_network.rda",
                        package = "PTMsToPathways")
load(pcn.path)
egfr_transporter_pcn <- filter.edges.between(
  "Transmembrane transport of small molecules",
  egfr_pathways, pathway.crosstalk.network)

This filtered PCN can be passed into the function cytoscape.graph.PCN.pathways to visualize the resultant network.
Note that this can go into Cytoscape because it has the Jaccard Similarity and Cluster Pathway Evidence (CPE) scores as distinct edges (rows). If you have Cytoscape installed and open, you can run the following code to visualize this new network.

# Graph PCN
pcn.graph <- cytoscape.graph.PCN.pathways(
  PCN = egfr_transporter_pcn,
  net.name = "EGFR signaling and transmembrane transporters",
  Jaccard.edges = TRUE)

This is the raw output into Cytoscape, but note that further modifications can be made to ensure easier viewing within the Cytoscape interface.

Let’s zero in on interactions between proteins in the two pathways “EGF/EGFR signaling pathway” and “Transmembrane transport of small molecules” because they have no genes in common, yet the cluster evidence for their interaction is strong. Note that we are checking both edge directions and combining the two results.

Because the Jaccard Score was zero, it was removed, leaving only the PTM_cluster_weight.

rbind(
  subset(pathway.crosstalk.network,
         target=="Transmembrane transport of small molecules" &
         source=="EGF/EGFR signaling pathway"),
  subset(pathway.crosstalk.network,
         source=="Transmembrane transport of small molecules" &
         target=="EGF/EGFR signaling pathway")
)
source target Weight interaction
295049 EGF/EGFR signaling pathway Transmembrane transport of small molecules 2.04637335631707 PTM_cluster_weights

First we extract a network of interactions between the genes in the two pathways. Then we generate a node file for Cytoscape. In the following case we include the data extracted from the ptmtable. This is optional, useful if node size and color is used later to indicate values in data.

cfn.path <- system.file("extdata",
                        "full_cfn.rda",
                        package = "PTMsToPathways")
load(cfn.path)

egfr_transporter.cfn <- filter.edges.0(c(
  pathways.list[["EGF/EGFR signaling pathway"]],
  pathways.list[["Transmembrane transport of small molecules"]]), cfn)

egfr_transporter.nodes <- make.cytoscape.node.file(
  egfr_transporter.cfn, function_key, ex_full_ptm_table, include.gene.data=TRUE)

Generate the graph and set node size and color

The function GraphCfn creates a graph using the cluster filtered network in the Cytoscape app. Cytoscape provides an interactive interface to view the data. This function requires the edge list file (egfr_transporter.cfn in the example), and node data file (egfr_transporter.nodes).

GraphCfn(cfn.edges = egfr_transporter.cfn, cfn.nodes = egfr_transporter.nodes,
         Network.title = "CFN", Network.collection = "PTMsToPathways")

The following graph should then become visible in Cytoscape.

Let’s color the nodes by the intensity of their response to Erlotinib. In general, we choose a ratio data column to show which proteins reacted to your study of choice.

setNodeColorToRatios(plotcol="PC9_ErlotinibRatio")

This should modify the previous graph into the following:

The existing cluster filtered networks retain parallel edges and self-loops. To consolidate these into a cleaner graph for the full cfn, you can run the following:

cfn.merged <- mergeEdges(cfn)

Or just to the filtered cfn made above:

egfr_transporter.cfn.merged <- mergeEdges(egfr_transporter.cfn)

Let’s look at the filtered cfn with merged edges in Cytoscape to compare:

GraphCfn(cfn.edges = egfr_transporter.cfn.merged,
         cfn.nodes = egfr_transporter.nodes,  Network.title = "CFN",
         Network.collection = "PTMsToPathways")

We again need to adjust the colors of the nodes to a specific interaction type as above.

setNodeColorToRatios(plotcol="PC9_ErlotinibRatio")

Note that within Cytoscape you can change the column for node size and color (two separate things) in the “Styles” tab.

Explore Signaling Pathways that Connect Proteins

Another example of how to use the network is to ask: What are the paths between two nodes (two proteins)? We use the function connectNodes.all() to identify all shortest paths between two nodes.

sp1 <- connectNodes.all(c("FYN", 'MET'), edgefile = cfn.merged)

Having identified the pathways, let’s also zoom in further on PTMs to examine which PTMs co-cluster, as indicated by yellow edges between them. To include this data in the graph, first run get.co.clustered.ptms then use the flag include.coclustered.PTMs when generating the Cytoscape node file:

ptmcccn.path <- system.file("extdata",
                            "full_ptm_cccn.rda",
                            package = "PTMsToPathways")
load(ptmcccn.path)

sp1_plus <- get.co.clustered.ptms(sp1, ptm.cccn.edges, ex_full_ptm_table)
sp1_plus.nodes <- make.cytoscape.node.file(sp1_plus, function_key, ex_full_ptm_table,
                                           include.gene.data = TRUE,
                                           include.coclustered.PTMs = TRUE,
                                           ptm.cccn.edges = ptm.cccn.edges)

As before, we can graph in Cytoscape and set the node color:

GraphCfn(cfn.edges = sp1_plus, cfn.nodes = sp1_plus.nodes,
         Network.title = "CFN/CCCN", Network.collection = "PTMsToPathways")

setNodeColorToRatios(plotcol = "H3122CrizotinibRatio")

Bottom-Up Approach

Instead of starting with pathways, we can also start by investigating the PTMs directly.

Investigate how dasatinib affects proteins involved in focal adhesion

Dasatinib exhibits strong binding and inhibitory effects on multiple focal adhesion-associated genes from the BioPlanet list:

• SRC (proto-oncogene tyrosine-protein kinase Src)

• FYN (tyrosine-protein kinase Fyn)

• EGFR (epidermal growth factor receptor)

• ERBB2 (receptor tyrosine-protein kinase erbB-2)

All these genes are directly implicated in focal adhesion signaling regulation. We hypothesize that ptms on proteins involved in focal adhesion will be downregulated by dasatinib.

First, we take only the Dasatinib experiments from our dataset, find the sum of their reactions to Dasatinib, and order them.

pt.sub <- ex_full_ptm_table[, grep("DasatinibRatio", names (ex_full_ptm_table))]
pt.sub$Sum.Dasat <- rowSums(pt.sub, na.rm = TRUE)
pt.sub <- pt.sub[order(pt.sub$Sum.Dasat, decreasing = FALSE), ]
head(pt.sub)
>>              H2286_DasatinibRatio H366_DasatinibRatio Sum.Dasat
>> PRKCD p Y313            -5.985065           -6.409734 -12.39480
>> EPHA2 p T587            -6.643856           -4.296287 -10.94014
>> EPHA2 p Y594            -6.643856           -4.229516 -10.87337
>> ERBB2 p Y877            -6.643856           -4.210496 -10.85435
>> PKP4 p T477             -6.006270           -4.532645 -10.53892
>> WASL p Y256             -4.470301           -6.051671 -10.52197

Now, we filter to only PTMs related to focal adhesion genes.

pt.sub$Gene.Name <- sapply(rownames(pt.sub), function(x){
  unlist(strsplit(x, " ",  fixed=TRUE))[1]})

fa.genes <- pathways.list[["Focal adhesion"]]
pt.sub.fa <- pt.sub[pt.sub$Gene.Name %in% fa.genes,]

We also retain those that down regulate a significant amount (<-2 decrease).

pt.sub.fa.topz <- pt.sub.fa[pt.sub.fa$Sum.Dasat < -2,]
ptms <- rownames(pt.sub.fa.topz)

Finally, we employ a PTMsToPathways functions to derive a cluster filtered network starting with the list of PTMs and then prepare the dataframe for Cytoscape visualization.

cfn.cccn <- ptms_to_cfn(ptms, cfn = cfn.merged, ptm.cccn.edges,
                        ex_full_ptm_table, pepsep = ";")

cfn_cccn.nodes <- make.cytoscape.node.file(cfn.cccn, function_key,
                                           ex_full_ptm_table,
                                           include.gene.data = TRUE,
                                           include.coclustered.PTMs = TRUE,
                                           ptm.cccn.edges = ptm.cccn.edges)

If you have Cytoscape installed, you can run GraphCfn to automatically view the network just created.

GraphCfn(cfn.edges = cfn.cccn, cfn.nodes = cfn_cccn.nodes,
         Network.title = "CFN/CCCN", Network.collection = "PTMsToPathways")

# Choose ratio data column to show which proteins' PTMs were inhibited by a dasatinib
setNodeColorToRatios(plotcol="H366_DasatinibRatio")
setNodeColorToRatios(plotcol="H2286_DasatinibRatio")
